Customized MxN Multimode ABS FBT Couplers Splitters, LC/SC/FC/ST
Contact us for bulk price
$18,90
In stock
In stock
-
Standard delivery
Trackable Standard Shipping
6-12 Days
-
DHL Courier delivery
3-6 Days
-
120 days Warranty and Money back Guarantee
Payment Methods:
Description
Features
- Low insertion loss
- High directivity
- Compact size
- High stability and reliability
Applications
- FDDI
- Communication system
- Accessing network
- Local area network
Specification
| Coupling ratio |
50：50 |
|
|---|---|---|
| Operating wavelength |
850±40nm or 1310±40nm |
|
| Grade |
P |
A |
| Max excess loss |
0.45dB |
0.55dB |
| Max insertion loss |
3.8dB |
4.0dB |
| Max uniformity |
0.7dB |
1.0dB |
| Min directivity |
≥35dB |
|
| Operating temperature |
-20℃～+85℃ |
|
| Storage temperature |
-40℃～+85℃ |
|
| Package dimension(mm) |
B=Φ3×54 for bare fiber or 900um fiber |
|
|
L=90*20*9.9 mm for 0.9mm or 2mm or 3mm cab |
||
Remark :
all specification does not include connector loss,with connector IL will be higher 0.2dB
Specification
Overview
| Weight | 1 kg |
|---|
