Sanyo Denki 9LB1424H501 fan

Name: Sanyo Denki 9LB1424H501 fan
Brand: HORVEX
SKU: 6448M
Price: 115.53 USD
Availability: InStock

SKU: 6448M

Fan Tubeaxial 24VDC Square – 140mm L x 140mm H Ball 208.5 CFM (5.84m³/min) 3 Wire Leads

Contact us for bulk price

$115,53

Trackable Standard Shipping

6-12 Days

3-6 Days

Payment Methods:

MPN:	6448M
Manufacturer:	Sanyo Denki America Inc.
Voltage – Rated:	24VDC
Air Flow:	208.5 CFM (5.84m³/min)
Noise:	49.0dB(A)
Power (Watts):	14.4 W
RPM:	3100 RPM
Termination:	3 Wire Leads
Size / Dimension:	Square – 140mm L x 140mm H
Width:	51.00mm
Static Pressure:	0.520 in H2O (129.5 Pa)
Bearing Type:	Ball
Fan Type:	Tubeaxial
Features:	Locked Rotor Protection, Speed Sensor (Tach)
Ingress Protection:	–
Operating Temperature:	-4 ~ 158°F (-20 ~ 70°C)
Approval Agency:	CSA, TUV, UL
Weight:	1.3 lbs (610.0 g)
Series:	San Ace 140L
Current Rating (Amps):	0.600A
Voltage Range:	20.4 ~ 27.6VDC
Material – Frame:	Aluminum
Material – Blade:	Plastic
Lifetime @ Temp.:	100000 Hrs @ 60°C
