Same Sky CFM-4015B-1135-415-22 fan

Name: Same Sky CFM-4015B-1135-415-22 fan
Brand: HORVEX
SKU: 9WFA0824G6D001
Price: 6.00 USD
Availability: InStock

SKU: 9WFA0824G6D001

Fan Tubeaxial 12VDC Square – 40mm L x 40mm H Ball 15.8 CFM (0.442m³/min) 4 Wire Leads

Contact us for bulk price

$6,00

Trackable Standard Shipping

6-12 Days

3-6 Days

Payment Methods:

MPN:	9WFA0824G6D001
Manufacturer:	Same Sky (Formerly CUI Devices)
Voltage – Rated:	12VDC
Air Flow:	15.8 CFM (0.442m³/min)
Noise:	41.5dB(A)
Power (Watts):	3.6 W
RPM:	13500 RPM
Termination:	4 Wire Leads
Size / Dimension:	Square – 40mm L x 40mm H
Width:	15.10mm
Static Pressure:	0.920 in H2O (229.2 Pa)
Bearing Type:	Ball
Fan Type:	Tubeaxial
Features:	Auto Restart, PWM Control, Speed Sensor (Tach)
Ingress Protection:	–
Operating Temperature:	14 ~ 158°F (-10 ~ 70°C)
Approval Agency:	CE, cURus, TUV
Weight:	–
Series:	CFM-40B
Current Rating (Amps):	0.300A
Voltage Range:	10.8 ~ 13.2VDC
Material – Frame:	Polybutylene Terephthalate (PBT)
Material – Blade:	Polybutylene Terephthalate (PBT)
Lifetime @ Temp.:	70000 Hrs @ 40°C

Weight	1 kg
MPN	9WFA0824G6D001
Noise	41.5dB(A)
Air Flow	15.8 CFM (0.442m³/min)
Power (Watts)	3.6 W
Voltage - Rated	12VDC
RPM	13500 RPM
Termination	4 Wire Leads
Manufacturer	Same Sky (Formerly CUI Devices)
