Delta AFB1224HE-F00 fan
Fan Tubeaxial 24VDC Square – 120mm L x 120mm H Ball 105.9 CFM (2.97m³/min) 3 Wire Leads
Contact us for bulk price
$13,00
-
Standard delivery
Trackable Standard Shipping
6-12 Days
-
DHL Courier delivery
3-6 Days
-
120 days Warranty and Money back Guarantee
Payment Methods:
Description
| MPN: | AFB1224HE-F00 |
| Manufacturer: | Delta Electronics |
| Voltage – Rated: | 24VDC |
| Air Flow: | 105.9 CFM (2.97m³/min) |
| Noise: | 41.0dB(A) |
| Power (Watts): | 5.76 W |
| RPM: | 2600 RPM |
| Width: | 38.00mm |
| Fan Type: | Tubeaxial |
| Series: | AFB |
| Size / Dimension: | Square – 120mm L x 120mm H |
| Static Pressure: | 0.300 in H2O (74.7 Pa) |
| Bearing Type: | Ball |
| Features: | Locked Rotor Protection, Speed Sensor (Tach) |
| Termination: | 3 Wire Leads |
| Ingress Protection: | – |
| Operating Temperature: | 14 ~ 140°F (-10 ~ 60°C) |
| Approval Agency: | CE, CSA, UL, VDE |
| Description: | FAN AXIAL 120X38MM 24VDC WIRE |
| Detailed Description: | Fan Tubeaxial 24VDC Square – 120mm L x 120mm H Ball 105.9 CFM (2.97m³/min) 3 Wire Leads |
| Current Rating (Amps): | 0.240A |
| Voltage Range: | 7 ~ 27.6VDC |
| Material – Frame: | Plastic |
| Material – Blade: | Plastic |
| Lifetime @ Temp.: | 70000 Hrs @ 40°C |
Specification
Overview
| Weight | 1 kg |
|---|---|
| MPN | |
| Termination | |
| Noise |
41.0dB(A) |
| Air Flow | |
| Power (Watts) | |
| Voltage - Rated | |
| RPM | |
| Manufacturer |
