Same Sky CFM-4020CF-155-212-20 fan

Name: Same Sky CFM-4020CF-155-212-20 fan
Brand: HORVEX
SKU: CFM-4020CF-155-212-20
Price: 6.00 USD
Availability: InStock

SKU: CFM-4020CF-155-212-20

Fan Tubeaxial 12VDC Square – 40mm L x 40mm H omniCOOL™ Magnetic Sleeve 6.9 CFM (0.193m³/min) 3 Wire Leads

Contact us for bulk price

$6,00

Trackable Standard Shipping

6-12 Days

3-6 Days

Payment Methods:

MPN:	CFM-4020CF-155-212-20
Manufacturer:	Same Sky (Formerly CUI Devices)
Voltage – Rated:	12VDC
Air Flow:	6.9 CFM (0.193m³/min)
Noise:	21.2dB(A)
Power (Watts):	0.72 W
RPM:	5500 RPM
Width:	20.00mm
Fan Type:	Tubeaxial
Series:	CFM-40CF
Size / Dimension:	Square – 40mm L x 40mm H
Static Pressure:	0.140 in H2O (34.9 Pa)
Bearing Type:	omniCOOL™ Magnetic Sleeve
Features:	Auto Restart, Speed Sensor (Tach)
Termination:	3 Wire Leads
Ingress Protection:	–
Operating Temperature:	14 ~ 158°F (-10 ~ 70°C)
Approval Agency:	CE, cURus, TUV
Description:	DC AXIAL FAN, 40 MM SQUARE, 20 M
Detailed Description:	Fan Tubeaxial 12VDC Square – 40mm L x 40mm H omniCOOL™ Magnetic Sleeve 6.9 CFM (0.193m³/min) 3 Wire Leads
Current Rating (Amps):	0.060A
Voltage Range:	10.8 ~ 13.2VDC
Material – Frame:	Polybutylene Terephthalate (PBT)
Material – Blade:	Polybutylene Terephthalate (PBT)
Lifetime @ Temp.:	40000 Hrs @ 40°C

Weight	1 kg
MPN	CFM-4020CF-155-212-20
Termination	3 Wire Leads
Noise	21.2dB(A)
Air Flow	6.9 CFM (0.193m³/min)
Power (Watts)	0.72 W
Voltage - Rated	12VDC
RPM	5500 RPM
Manufacturer	Same Sky (Formerly CUI Devices)
