Fan-S Division / Qualtek Electronics Corp. FDD1-17251EBLW33 fan

Name: Fan-S Division / Qualtek Electronics Corp. FDD1-17251EBLW33 fan
Brand: HORVEX
SKU: FDD1-17251EBLW33
Price: 6.66 USD
Availability: InStock

SKU: FDD1-17251EBLW33

Fan Tubeaxial 48VDC Rectangular/Rounded – 172mm L x 151mm H Ball 255.0 CFM (7.14m³/min) 3 Wire Leads

Contact us for bulk price

$6,66

Standard delivery

Trackable Standard Shipping

6-12 Days

DHL Courier delivery

3-6 Days

120 days Warranty and Money back Guarantee

Payment Methods:

Description

MPN:	FDD1-17251EBLW33
Noise:	56.0dB(A)
Air Flow:	255.0 CFM (7.14m³/min)
Power (Watts):	21.6 W
Voltage – Rated:	48VDC
RPM:	3200 RPM
Termination:	3 Wire Leads
Manufacturer:	Fan-S Division / Qualtek Electronics Corp.
Size / Dimension:	Rectangular/Rounded – 172mm L x 151mm H
Width:	51.00mm
Static Pressure:	0.736 in H2O (183.3 Pa)
Bearing Type:	Ball
Fan Type:	Tubeaxial
Features:	Locked Rotor Sensor
Ingress Protection:	IP54 – Dust Protected, Water Resistant
Operating Temperature:	-4 ~ 158°F (-20 ~ 70°C)
Approval Agency:	CE, cURus, TUV
Weight:	2.5 lbs (1.1 kg)
Series:	HPLC, FDD1-17251
Current Rating (Amps):	0.450A
Voltage Range:	–
Material – Frame:	Aluminum
Material – Blade:	Plastic
Lifetime @ Temp.:	50000 Hrs @ 25°C
Detailed Description:	Fan Tubeaxial 48VDC Rectangular/Rounded – 172mm L x 151mm H Ball 255.0 CFM (7.14m³/min) 3 Wire Leads

Specification

Overview

Weight	1 kg
MPN	FDD1-17251EBLW33
Noise	56.0dB(A)
Air Flow	255.0 CFM (7.14m³/min)
Power (Watts)	21.6 W
Voltage - Rated	48VDC
RPM	3200 RPM
Manufacturer	Fan-S Division / Qualtek Electronics Corp.
