Orion (Knight Electronics, Inc.) OD1238-24MBIP68 fan

Name: Orion (Knight Electronics, Inc.) OD1238-24MBIP68 fan
Brand: HORVEX
SKU: OD1238-24MBIP68
Price: 67.00 USD
Availability: InStock

SKU: OD1238-24MBIP68

Fan Tubeaxial 24VDC Square – 119.5mm L x 119.5mm H Ball 115.0 CFM (3.22m³/min) 2 Wire Leads

Contact us for bulk price

$67,00

Standard delivery

Trackable Standard Shipping

6-12 Days

DHL Courier delivery

3-6 Days

120 days Warranty and Money back Guarantee

Payment Methods:

Description

MPN:	OD1238-24MBIP68
Noise:	41.0dB
Air Flow:	115.0 CFM (3.22m³/min)
Power (Watts):	4.6 W
Voltage – Rated:	24VDC
RPM:	2600 RPM
Termination:	2 Wire Leads
Manufacturer:	Orion (Knight Electronics, Inc.)
Size / Dimension:	Square – 119.5mm L x 119.5mm H
Width:	38.00mm
Static Pressure:	0.430 in H2O (107.0 Pa)
Bearing Type:	Ball
Fan Type:	Tubeaxial
Features:	Auto Restart
Ingress Protection:	IP68 – Dust Tight, Waterproof
Operating Temperature:	5 ~ 149°F (-15 ~ 65°C)
Approval Agency:	cURus, TUV
Weight:	0.572 lb (259.45 g)
Series:	OD1238
Current Rating (Amps):	0.190A
Voltage Range:	–
Material – Frame:	Polybutylene Terephthalate (PBT)
Material – Blade:	Polybutylene Terephthalate (PBT)
Lifetime @ Temp.:	65000 Hrs @ 45°C
Detailed Description:	Fan Tubeaxial 24VDC Square – 119.5mm L x 119.5mm H Ball 115.0 CFM (3.22m³/min) 2 Wire Leads

Specification

Overview

Weight	1 kg
MPN	OD1238-24MBIP68
Noise	41.0dB
Air Flow	115.0 CFM (3.22m³/min)
Power (Watts)	4.6 W
Voltage - Rated	24VDC
RPM	2600 RPM
Manufacturer	Orion (Knight Electronics, Inc.)
